No.
|
Item
|
Performance
|
|
1
|
使用溫度範圍
OperatingTemperatureRange
|
-40 to +1050C
|
-25 to +1050C
|
|
2
|
定格電壓範圍
RatedWorkingVoltageRange
|
6.3-100V.DC
|
160~450V.DC
|
|
3
|
靜電容量範圍
Capacitance Tolerance
|
0.47-15000μF
|
0.47-470μF
|
|
4
|
靜電容量容許差
Capacitance Tolerance
|
±20%(at+20 0C,120Hz)
|
|
5
|
洩漏電流
Leakage Current
|
I ≤0.01CV or3(μA) after
three minutes
Application of rated working voltage +20℃
|
I ≤0.03CV after
three minutes
Application of rated working voltage +20℃
|
|
6
|
損失角
Dissipation Factor(tanδ)
（120Hz\+20℃）
|
|
Working
Voltage（V）
|
6.3
|
10
|
16
|
25
|
35
|
50
|
63
|
100
|
160~250
|
350,400
|
450
|
|
tanδ max.
|
0.18
|
0.16
|
0.14
|
0.12
|
0.10
|
0.09
|
0.08
|
0.08
|
0.12
|
0.15
|
0.17
|
For capacitance value ＞1000μF, add 0.02 per another 1000μF
|
|
7
|
低溫度特性（at 120 Hz）
Characteristics at low temperature （Impedance ratio at 120Hz）
|
|
Working Voltage（V） (V)
|
6.3
|
10
|
16
|
25~50
|
63,100
|
160
|
200
|
250
|
350
|
400
|
450
|
|
Z-25℃/+20℃
|
4
|
3
|
3
|
3
|
2
|
2
|
2
|
3
|
5
|
5
|
6
|
|
Z-40/℃+20℃
|
8
|
6
|
4
|
3
|
3
|
3
|
6
|
6
|
6
|
6
|
-
|
|
|
8
|
高溫負荷特性
High Temperature Loading
|
|
D?
|
≤8?
|
≥10?
|
|
Life hours
|
3000
|
5000
|
|
|
Application of DC rated working voltage at +105℃,
The capacitor shall meet the following
limits:
Post test requirements at +20℃
|
Leakage
current
|
≤ the Initial specified value
|
|
Capacitance
change
|
≤±25% of initial measured value
|
|
Dissipation
Factor(tanδ)
|
≤200% of initial specified value
|
|
|
9
|
高溫?zé)o負荷特性
Shelf Life
|
After 1000hrs. Application of DC no rated working voltage at +105℃,The capacitor shall meet the following limits: Post test
requirements at +20℃
|
Leakage
current
|
≤200% of initial specified value
|
|
Capacitance
change
|
≤±20% of initial measured value
|
|
Dissipation
Factor(tanδ)
|
≤200% of initial specified value
|
|
